Product description

275g/㎡ zinc coating is used for the fan fairing, which increases its thickness and ensures no rusting in future use. The design of inverting side-flow is used to increase ventilation, reduce the vibration and noise of the fan and increase its stability. The Fan Blades are calibrated by the advanced computer dynamic balance Tester to make the fan run smoothly, reduce noise, enhance stablity and prolong service life. The Motor is made of aluminum-magnesium alloy with good heat dissipation, high efficiency , small ize, light weight,low current and large torque.

Technical Parameter

Model Specification	Diameter biades (mm)	Blades rotational speed rpm	Motor rotational speed rpm	Air flow(m³/h)	Total presure	Nosie decibels	Import power（W）	Rated voltage（V）	Height（mm）	width（mm）	Thickness（mm）
JW-800	710	612	1400	18000	75	≤70	370	380	800	800	250
JW-900	750	616	1400	22000	65	≤65	550	380	900	900	260
JW-1000	900	513	1400	23000	70	≤70	550	380	1000	1000	260
JW-1100	1000	513	1400	32500	70	≤70	750	380	1100	1100	270
JW-1220	1100	427	1400	38000	73	≤70	1100	380	1220	1220	280
JW-1380	1350	427	1400	44000	56	≤75	1100	380	1380	1380	290
JW-1530	1400	427	1400	55800	60	≤70	1500	380	1530	1530	300
